HYDRAULIC 4 ROLL DOUBLE PINCH TYPE PLATE BENDING MACHINES
RANGE : 2050 TO 4100 MM, THICKNESS: 4 TO 100 MM
MODEL W4RHH, MODEL W4RHM
WELDOR plate bending machines are available in SIX different ranges, All range of
machine has a different mechanism, specifications and systems for suitable applications
and production rate. Type W4RHH / W4RHM / W3RHH / W3RHM /W3RMM / W3RML.
Model W4RHH is very suitable for medium and heavy plates or stainless steel, Model W4RHM is very suitable for light and medium plates. All other technical specification,
standard & optional equipment is as under:
TECHNICAL SPECIFICATIONS AND STANDARD ACCESSORIES
OPTIONAL EQUIPMENTS
Pipes in full circle or varying radiuses
can be done easily.
Bottom roll and side rolls move
with hydraulic cylinders.
Overload protection.
Top roll and bottom rolls are drives by
hydraulic motor and Planetary gearbox.
Hydraulic drop-end for easy removal
of finished pipes.
Easy operation with mobile control panel.
Welded steel frames.
Forged or rolled steel rolls.
Manual central lubrication system.
Hydraulic and electrical balancing system.
Users manual.
Cone bending device
Double speed working system
Hydraulic lateral supports for large
diameters
Extended rolls.
Profile rollers.
Automatic centralized lubrication system.
Material feed table.
Overhead crane for large diameters.
Digital readout display.
NC control system.
Note: Specifiation / Design are
subject to change without prior notice.
